FTA 1 Anemometer - Geo Fennel
- Wind speed measurement: 0.4 ~ 30 m/s.
- Airflow measurement: 0 ~ 9,999 m3/min.
- Air temperature measurement: -10°C – +60°C.
- Impeller sensor.
- 1.2m sensor cable.
- 2-line display on LCD screen.
- 1 9V battery.
Introduction
The FTA 1 Geo Fennel handheld anemometer is a multifunctional portable wind measuring device designed specifically for measuring wind speed, airflow, and air temperature in HVAC and industrial systems. It is an authentic Geo Fennel import from Germany, manufactured in China, offering stable quality at a reasonable price.
Equipped with a 65mm diameter impeller sensor with a 1.2m extension cable, the device allows accurate and flexible measurements in various working environments. The LCD screen clearly separates parameters for easy monitoring and operation.
FTA 1 is suitable for technicians, supervisors, and investors who need to inspect and accept ventilation systems, industrial fans, or other measurement applications.
Introduction Video
Features
- Three main functions: measure wind speed, airflow, and air temperature.
- Wide wind speed measurement range from 0.4 m/s to 30 m/s with high accuracy ±3% + fixed error.
- Airflow measurement up to 9,999 m³/min or ft³/min, allowing input of duct cross-section for automatic flow calculation.
- Air temperature measurement from -10°C to +60°C with accuracy ±2°C.
- Wide LCD screen displaying 2 lines: temperature on top and speed/flow below.
- MAX, MIN, AVG, HOLD function keys for professional and convenient operation.
- 65mm diameter impeller sensor with 1.2m cable allows flexible measurements at various positions.
- Memory stores 20 speed readings and 16 cross-section slots for convenient use.
- Low battery alert ensures measurement accuracy.
Applications
- Inspecting and measuring wind speed and airflow in building ventilation systems, air vents, and exhaust ducts after installation.
- Supporting HVAC project acceptance for technicians, consultants, supervisors, and investors.
- Checking quality of industrial fans and desk fans to ensure design compliance.
Technical Specifications - FTA 1 Geo Fennel Handheld Anemometer
Wind Speed
- 0.4 ~ 30 m/s; accuracy ±3% + 0.2; display unit 0.01 m/s.
- 1.4 ~ 108 km/h; accuracy ±3% + 0.8; unit 0.1 km/h.
- 0.9 ~ 67 MPH; accuracy ±3% + 0.4; unit 0.1 MPH.
- 0.8 ~ 58 knot; accuracy ±3% + 0.4; unit 0.1 knot.
- 80 ~ 5900 ft/min; accuracy ±3% + 40; unit 1 ft/min.
Airflow
- 0 ~ 9,999 m³/min (CMM); unit 0.001.
- 0 ~ 9,999 ft³/min (CFM); unit 0.001.
Air Temperature
- -10°C – +60°C; accuracy ±2°C; unit 0.1°C.
- +14°F – +140°F; accuracy ±4°F; unit 0.1°F.
General Information
- Device size: 75 x 203 x 50 mm.
- Weight: 280 g.
- Battery: 1 alkaline 9V square battery, 80 hours usage time.
Package Contents
- 1 handheld meter FTA 1, genuine import from Geo Fennel, Germany.
- 1 impeller sensor set with 120 cm cable.
- 1 disposable 9V alkaline square battery.
- 1 carrying case for device and accessories.
- 1 user manual.
- 1 12-month official warranty card from Le Quoc Equipment.
